Lenco 101 Standard Actuator - 12V - 2-1/4" Stroke [15054-001]

The Lenco 101 is a 12V electric actuator listed for Standard, Edge Mount, and Standard Performance kits. Its instant-response design uses high-impact, glass-fiber-filled, UV-resistant nylon and 316 super-buff stainless steel tubing.

Dimensions and fit

• Stroke: 2.25 inches.
• Listed overall length: 12.5 inches (described as “tip to top” in the supplied copy).
• Includes 5/16-inch mounting hardware and a 6 ft cable.

Specifications:

• Newly implemented Anti Extrusion Ring (AXR) seal stabilization system.
• Stronger top cap and mounting clevis design
• Improved pressure-tight torx screws
• Integrated wiper seal at actuator base
• Molded-in brass thrust bearing design
• Thicker and stronger motor housing wall
• Improved O-Ring design for more consistent seal
• Over-molded cable providing a stronger tighter seal
• Upper mounting bracket with gland seal

Features:

• Lenco's ballscrew design is more reliable and twice as powerful compared to typical hydraulics
• Lenco's tough, high-torque actuator motor easily pushes 500 pounds.
• Lenco Actuator connections use waterproof "Plug & Play" Deutsch connectors eliminating the possibility of water intrusion.
• 12 Volt
• 5/16" mounting hardware
• 6 foot cable

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
